防爆圓筒狀直型釬子
圖示-(防爆圓筒狀直型釬子)圖片
用途：易燃易爆場所打鑿眼孔的工具
材質：鈹銅合金、鋁銅合金
規格及主要技術參數：
|
Number 序號 |
L mm |
Φ mm |
Φ1 mm |
Be-Cu g |
AI-Cu g |
|
1253-001 |
150 |
8 |
11 |
125 |
118 |
|
1253-002 |
150 |
10 |
13 |
155 |
140 |
|
1253-003 |
150 |
12 |
15 |
215 |
190 |
|
1253-004 |
200 |
14 |
18 |
420 |
380 |
|
1253-005 |
200 |
15 |
19 |
435 |
390 |
|
1253-006 |
200 |
16 |
20 |
480 |
435 |
|
1253-007 |
200 |
17 |
21 |
570 |
540 |
|
1253-008 |
250 |
18 |
22 |
600 |
560 |
|
1253-009 |
250 |
19 |
23 |
860 |
780 |
|
1253-010 |
250 |
20 |
24 |
875 |
790 |
|
1253-011 |
250 |
21 |
25 |
950 |
885 |
|
1253-012 |
250 |
22 |
26 |
965 |
920 |
|
1253-013 |
250 |
24 |
28 |
1270 |
1150 |
|
1253-014 |
250 |
25 |
29 |
1300 |
1170 |
|
1253-015 |
250 |
26 |
30 |
1390 |
1250 |
|
1253-016 |
300 |
27 |
31 |
1900 |
1770 |
